Model No.: EWG10000F
Jenama: TEMPAHAN OEM BOLEH DITERIMA
Sumber Kuasa: Elektrik
Permohonan: ATV / UTV
Voltan: 24V, 12V
Pembungkusan: KARTON EKSPOR
Pengangkutan: Ocean,Air
Tempat asal: CHINA
Port: NINGBO,SHANGHAI
Jenis bayaran: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF
No. Item Win Elektrik 10000 lbs EWG10000F dengan kotak kawalan gaya berdiri tegak yang juga merupakan wakil win pemulihan 4×4 luka siri generasi pertama kami. Ia sesuai untuk kereta offroad atau Jeep. Ia memenangi reputasi hebat kerana kualiti yang baik, harga yang berpatutan dan prestasi yang baik.
Ciri-ciri:
1. Klac kili percuma
2. Tindakan brek kon skru automatik
3. Pemacu kuasa DC 12V atau DC 24V pilihan
4. Motor Luka Bersiri
5. Alat kawalan jauh melalui kotak kawalan dan suis
6. Kawalan jauh wayarles tersedia jenis F tetap dalam kotak kawalan
7. SWR tensioner tersedia
EWG10000
| SPECIFICATION |
|
| Rated line pull | 10000 lbs (4536 kgs) |
| Motor: Series Wound |
12V:Input: 3.6kW / 4.8hp; Output: 2.7kW / 3.6hp
24V:Input: 4.8kW / 6.4hp; Output: 3.0kW /4.0hp |
|
|
|
| Gear reduction ratio | 294:1(12V); 210:1(24V) |
| Cable (Dia.× L) | Ø3/8 “×85 ‘ (Ø9.2mm×26m) |
| Drum size (Dia.× L) | Ø2.48 “×8.9 ” (Ø63mm×227 mm) |
| Mounting bolt pattern | 10 “×4.5 ” (254mm×114.3 mm) 4-M10 |
| Pull Speed Amperes Volts First layer | Line Pull And Rope Capacity In Layer | ||||||
|
Line Pull
Ibs (kgs) |
Line Speed
Ft/min (m/min) |
Current
A |
Layer
of cable |
Rated line pull
lbs(kgs) |
Total Rope On Drum
ft (m) |
||
|
|
12V DC | 24V DC | 12V DC | 24V DC | 1 | 10000(4536) | 18.0 (5.5) |
| 0 | 17.1 (5.2) | 23.0(7.0) | 80 | 50 | 2 | 8000 (3629) | 39.4 (12.0) |
| 4000(1814) | 7.9 (2.4) | 10.5(3.2) | 170 | 115 | 3 | 6600(2994) | 64.0(19.5) |
| 6000(2722) | 6.2 (1.9) | 8.2(2.5) | 210 | 145 | 4 | 5600(2540) | 85.3(26.0) |
| 8000(3629) | 5.6 (1.7) | 6.9(2.1) | 250 | 170 |
|
|
|
| 10000(4536) | 4.6 (1.4) | 5.9(1.8) | 300 | 200 |
|
|
|
| ITEM | EWG10000U | EWG10000S | EWG10000F |
| Overall dimensions |
22.4″×7.1″×9.6″
570mm×180mm×243mm |
22.4″×7.1″×11.7″
570mm×180mm×297mm |
22.4″×7.1″×10.6″
570mm×180mm×270mm |
| (L×W×H) | |||
| Net weight (Ibs) |
73.8
33.8 |
75.0
34.0 |
75.3
34.2 |
| (kgs |
Dimensi keseluruhan: 22.4″ x 7.1″ x 10.6″
(L x W x T) 570mm x 180mm x 270mm
Berat Bersih: 34.2 KGS
Kategori produk : Win Elektrik > Win 4x4
